Features

  • NMI Approved
  • Maintenance free
  • High accuracy (+/-0.5% +/-5mm/s)
  • Long life internal lithium battery
  • Compact or remote mountable converter display
  • 200,000 line inbuilt active data logger – standard
  • 4-20mA output (externally powered) – standard
  • Pulse output – standard
  • Alarm contact output – standard
  • Inbuilt 3G communications – optional
  • Sizes 15mm – 2000mm flanged
  • PN16 , PN25 or PN40 pressure ratings available
  • Ebonite liner  standard (80mm size and larger)
  • Teflon liner standard  (50mm size and smaller)
  • Fully potted internals
  • Hastalloy electrodes
  • Empty pipe detection

Description

Robust Sensor

The MUT2200 sensor is ideal for harsh applications.

It has fully potted internals to protect the coils against vibration and moisture ingress.  Hastelloy C electrodes as standard and a Teflon liner for sizes up to 50mm and Ebonite hard rubber for sizes 65mm and above.  With no moving parts it is maintenance free.

Sophisticated Display

The MC608 converter boast a large configurable display showing all critical flow data – see below video “how to read and configure the Euromag MC608”

It has pulse and alarm contact outputs and an onboard 200,000 line data logger as standard for simply extraction of critical historical flow data – see below video “how to download data logs from a MC608”

Make enquiry

Downloads
