WW-C30-P-AC Combination PN16 Air Release Valve with Assisted Closure

Features

  • Available in threaded BSP male in DN50 (2018 model with black cover, previously red)
  • Available in flanged DN50 & DN80 sizes
  • Standard Assisted Closure avoids water hammer during column separation
  • Low pressure sealing feature
  • Valves fully approved for drinking water installations to AS4956 & AS4020

Description

The Bermad C30-AC is a triple function combination air valve with assisted closure feature (design of anti-slam function), designed to limit water hammer in the event of column separation.

The assisted closure feature controls air discharge to avoid air valves “slamming shut”, which in turn generates water hammer. Valves are typically used on pump discharge manifolds and along the pipeline at locations where there is a possibility of column separation.

The valves are fully approved for drinking water purposes and have certification to AS4956 & AS4020
