Irrigation S-982-3W DC Latch Solenoid 2 Wire

Features

Aֺֺdvanced Construction Materials

  • Proven pressure, voltage and weather resistance
  • Highly durable in corrosive environments
  • Protection Class- IP68; NEMA Type 6D

Dֺֺry Actuator and Superb Finish

  • Reliable operation under dirt loaded water
  • Suitable to turbid, muddy and/or corrosive water

Sֺֺhort Electrical Impulse Latch Activation

  • Extremely low power consumption
  • Low voltage battery operation
  • Saves wires and infrastructures
  • Suites most Battery Operated Controllers on the market
  • Applicable in solar activated systems

Hֺֺydraulic Base with Installation Bracket

  • High flow capacity quickens valve response
  • Manual override open and close
  • Simple installation to valve or manifold

Rֺֺeliable and Durable Product that Bears the Stamp of BERMAD Quality

Description

The BERMAD S-982-3W-BB is a compact 3-Way Latching Solenoid Pilot Valve, comprised of two main components: a dry solenoid actuator and a 3-way hydraulic pilot valve. The actuator is neutralized from water damages by an isolating membrane, which hermetically isolates it from the water. The Model S-982-3W-BB consumes power only when switching positions, using a very short electric impulse. This prolongs life of batteries and enables solar recharging. The hydraulic base features a manual override and consists of a bracket for attaching to the valve or to a solenoid manifold.

Optional Brass base 16 bar
