GALIT hydraulic relay

Description

This Plastic 3-Way, single chamber accelerator is a hydraulically operated, diaphragm actuated pilot valve that in response to pressure applied to its control chamber, directs flow and pressure between its ports:

•  When pressure is applied to its control chamber, it connects port “3” to “4”.

•  When pressure is released from its control chamber, it connects port “2” to “4”.

The Galit can be used to either relay and accelerate a signal (N.O.), or to reverse and accelerate a signal (N.C.). It also features Manual Override.
